嵌鑲式無截獲柵柵控電子槍的研究
AN INVESTIGATION ON THE NON-INTERCEPTING GRIDDED ELECTRON GUN WITH A SHADOW GRID EMBEDDED IN CATHODE
-
摘要: 本文給出了一種無截獲柵糊控電子槍模型。陰影柵被直接嵌鑲在陰極面上,陰影柵采用環形椰網,在計算機輔助設計中提出了簡化二維數學模型并建立了計算程序。通過對計算機計算結果的分析,提出了設計這種槍的方法。并通過設計一個導流系數為0.9P的柵控槍進行了實驗驗證。初步結果表明建立的計算機程序完全可以滿足這一類無截獲柵柵控電子槍的工程設計要求。
-
關鍵詞:
Abstract: A kind of non-intercepting gridded gun is described, in which an annular grid-mesh type shadow grid is immediately embedded in the cathode. A simplified two-dimensional ma-thematical model is presented for computer aided design. Through investigation of the resu-Its of this computation a method of designing such a gun is presented. An experiment on a non-intercepting gridded gun with a perveance of 0.9 P is carried out. The obtained resu-Its prove that the computer program proposed here satisfies fully the design demand of this kind of non-intercepting gridded gun. -
李崇山、宋培德,柵控雙模電子槍計算機研究雙模槍第一階段,電子對抗微波管交流會文獻,1979年4月,廣州.[2]電子管設計手冊編委會,微波管電子光學系統設計手冊,國防工業出版社,1981年.[3]李崇山等,電子科學學刊, 5(1983), 116. -
