IC缺陷輪廓的分形插值模型
FRACTAL INTERPOLATION MODEL OF IC DEFECT OUTLINES
-
摘要: 現用于集成電路(IC)成品率預報及故障分析的缺陷模型均是用圓或正方形來代替真實缺陷的復雜輪廓進行近似建模的，從而在模型中引入了很大的誤差。本文利用分形插值的思想直接對真實缺陷的輪廓進行模擬，從而提出了一種新的缺陷輪廓表征模型。實驗結果表明：與傳統的最大圓模型、最小圓模型及橢圓模型相比，新模型的建模精度有了很大的提高。
-
關鍵詞:
- IC缺陷;分形插值;IC故障;IC成品率;等效圓形缺陷
Abstract: Available defect outline model used for yield prediction and inductive fault analysis of integrated circuits (IC) all model a real defect by replacing its real rugged outlines with circular discs or squares,then great errors were aroused in these models.Based on the idea of fractal interpolation,this paper presents a new model to characterize those real defect outlines.The comparison of the new model with those models available indicates that the new model is a more accurate defect outline model. -
Ferguson F J,Shen J P.Extraction and simulation of realistic CMOS faults using inductive fault analysis,presented at the Internat.Test Conf.,Paris:1988,136-140.[2]Prabhu A V F.Modeling the critical area in yield forecasts,IEEE J[J].of Solid-State Circ.1985,20(4):874-878[3]Lukaszek W,Yarbrough W,Walker T,Meindl J.CMOS test chip design for process problem debugging and yield prediction experiments,Solid State Technol.,1986,29(3):87-93.[4]Spiegel G,Stroele A P.Optimization of deterministic test sets using an estimation of product quality,Presented at the Asian Test Symp.,Bejing,China:Nov.1993,67-72.[5]Hess C,Strole A.Modeling of real defect outlines for defect size distribution and yield prediction,Proc.IEEE Int.Conference on Microelectronics Test Structures,March 1993,45-50.[6]姜曉鴻，郝躍等．IC制造中的真實缺陷輪廓表征方法研究，電子學報，1998，26(2)：11-14．[7]林鴻溢等．分形論-奇異性探索．北京：北京理工大學出版社，1992，98-125．[8]姜曉鴻，郝躍，徐國華．IC制造中的真實缺陷輪廓的分形特征．半導體學報，19(2)：123-126．[9]姜曉鴻，郝躍，徐國華．IC缺陷輪廓的盒維數及其方向的分布特征．半導體學報，19(8)：625-630．[10][英]肯尼思．法爾可內著，曾文曲等譯．分形幾何數學基礎及其應用．沈陽：東北大學出版社，1993，110-130．[11]姜曉鴻，郝躍，徐國華. Goodness-of-FIT tests for distributions of the ratio dmax/dmin of the real defect outlines in the IC manufacturing process.J.of Xidian University,1997, 24(增刊):35-50.[12]中山大學數學力學系編．概率論及數理統計(下冊)．北京：高等教育出版社，1985，138-150． -
