寬帶雙路轉動接頭的研究
DEVELOPMENT OF TWO WAY ROTARY JOINT WITH WIDE FREQUENCY BAND
-
摘要: 本文介紹一種寬帶雙路轉動接頭,兩路設計在同一工作頻段,在0.7GHz～1.4GHz頻帶內電壓駐波比小于1.3,插入損耗小于0.5dB,兩路之間的隔離大于40dB。轉動接頭采用兩點對稱激勵,套筒式結構,其長度短于/4。該轉動接頭的結構新穎而簡單,加工和調試方便,具有體積小,重量輕的特點,滿足了特定的小尺寸要求。
-
關鍵詞:
- 雙路轉動接頭; 低通濾波器; 寬帶; 三導體同軸線
Abstract: A wide frequency band two-way rotary joint (in the same frequency band) is described. Its VSWR is less than 1.3 over the frequency range from 0.7 GHz to 1.4GHz, its insert loss is less than 0.50dB, its isolation is better than 40dB. The rotary joint uses two symmetic excitation points and muff structure, and its length is shorter than /4. The structure is simple. Its fabrication and adjustment are easy. And it is light and small. The specified small size requirment is satisfied. -
Yin Liansheng. Journal of Electronics (China), 1992, 9(2): 187-192.[2]清華大學微帶電路編寫組.微帶電路.北京:人民郵電出版社,1976,第二章第四節.[3]甘本袚,吳萬春.現代微波濾波器的結構與設計.北京:科學出版社,1973.[4]章文勛.無線電技術中的微分方程.北京:國防工業出版社,1982,第十一章第四節.[5]Gunston M A R. Microwave Transmission Line Impedance Data. Great Baddow: Van Nestrand Reinhold Company, 1971, 36-37.[6]梁昌洪.計算微波.西安:西北電訊工程學院出版社,1985,第三章第十節. -
