探地雷達中蝶形振子天線的改進
Improvement on Bow-Tie Antenna of Ground-Penetrating Radar
-
摘要: 探地雷達是進行地下環境無損探測的一種有效工具,用來探測和識別地下目標,比如水管、電力線和通信線路、考古方面的保護等.然而,傳統的探地雷達系統在可靠性、分辨率、探測深度等方面存在不足.因此,改善被測信號特性,設計和開發更高性能的天線就顯得很有必要.本文研制了一種貼片電阻加載的蝶形振子天線,用時域有限差分方法對其進行了分析,實際應用結果表明天線具有良好的波形保真度,良好的輻射特性和屏蔽效果.可以廣泛地應用于探地雷達和其它超寬帶系統.
-
關鍵詞:
- 蝶形振子;時域有限差分方法(FDTD);探地雷達
Abstract: The ground penetrating radar is greatly expected as an effective tool for nondestructively sensing subsurface environment, detecting and identifying underground objects such as water pipes, power and communication lines, archaeological remains, and so on. However, conventional ground penetrating radar systems are still insufficient for practical uses with respect to reliability, resolution, detectable depth, and so forth. In order to overcome these difficulties, it is important to improve characteristics of signals to be measured. Therefore, the design and development of antennas of higher performances would be invaluable. This paper designed a bow-tie antenna loaded by lumped resistors. Results of finite difference time domain calculation show good fidelity of the wave, and exciting radiation features as well as effect of shielding. It can be widely used in ground penetrating radar and other tra-wide-band systems. -
Maloney J G, Smith G S. Optimization of a conical antenna for pulse radiation: An efficient design using resistive loading. IEEE Trans. on AP, 1993, 41(7): 940-947.[2]Farr E G, Baum C E: Impulse Radiating Antennas Ultra-wide Band Short-pulse Electro-magnetic. New York, Plenum Press,1995, Chap. 1.[3]Robertson R C, Mogran M A. Ultra-Wideband Antenna for High-Power Operation Ultra-wide Band, Short-Pulse Electrom agnetic. New York and London, Plenum Press, 1993, Chap.2.[4]Liu Kecheng, He Jianguo: Analysis and design of UWB TEM horn with waveform high fidelity. Journal of NUDT, 1994, 16 (1):57-63.[5]袁乃昌,何建國,等.新型集成超寬帶開槽天線的研制及其應用.電子學報,1997,25(9):43-46.[6]Darden W H, Burnside W D. An ultra-wide band antenna for pulse application. Microwave Journal, 1993, 36(1): 136-143.[7]Shlager K L, Smith G S, Maloneny J G. Optimization of bow-tie antenna for pulse radiation. IEEE Trans. on AP, 1994, 42(7):975-982.[8]劉克成,何建國,尹家賢,劉培國.超寬帶圓錐TEM喇叭天線的分析與設計.微波學報,1995,11(1):66-70. -
