參數微擾方法對Boost變換器的混沌控制
Small Parametric Perturbation Method in Controlling Boost Converter
-
摘要: 該文使用參數微擾方法控制電流控制模式Boost變換器在連續電流模式下產生的混沌行為。文中利用離散模型確定了系統運行的混沌區域,并在設計控制環時作了適當?shù)暮?jiǎn)化,以利于實現。仿真分析和實驗都顯示,這一方法對于開關電路是有效的。電路的穩定被重新建立,并在此基礎上進一步擴大了變換器的工作范圍,文中還分析了噪聲在控制中的影響。
-
關鍵詞:
- Boost變換器; 分岔; 混沌控制
Abstract: OGY method(1990) is applied to control the chaos exhibited by current-mode controlled boost dc-dc converter, as its chaotic regime has been established in this paper. This is achieved by using discrete-time model and making simplification of the control loop design. Both simulation and experiment are done. Stability of the circuit is obtained, which proves this control method is valid in controlling switching circuit. -
Deane J H B. Chaos in a current-mode controlled boost dc-dc converter. IEEE Trans. on Circuits and Systems-I, 1992, CAS-I-39(8): 680-683.[2]Banerjee S, Chakrabarty K. Nonlinear modeling and bifurcation in the boost converter[J].IEEE Trans. on Power Electronics.1998, 13(2):252-260[3]Chan W C Y, Tse C K. Study of bifurcations in current programmed dc/dc boost converters:Form qusiperiodicity to period doubling. IEEE Trans. on Circuits and Systems-I, 1997, CAS-I-44(12): 1129-1142.[4]Pyragas K. Continuous control of chaos by self-controlling feedback[J].Phys. Lett. A.1992, 170:421-428[5]G. Chen, X. Dong. On feedback control of chaotic nonlinear dynamic systems. Int. J. Bifurcation and Chaos, 1992, 2(2): 407-411.[6]Poddar G, Chakrabarty K, Banerjee S. Control of chaos in dc-dc converters. IEEE Trans. on Circuits and Systems-I, 1998, CAS-I-45(6): 672-676.[7]Ott E, Grebogi C, Yorke J. Controlling chaos[J].Phys. Rev. Lett.1990, 64(11):1196-1199 -
