施密特電路的時序特征及門級設計
THE SEQUENTIAL CHARACTERISTIC OF SCHMITT CIRCUIT AND ITS DESIGN AT GATE LEVEL
-
摘要: 該文根據施密特電路對輸入信號具有兩種檢測閾值的工作特點,提出了施密特電路與用作存貯元件的觸發器之間具有相同的時序特征。利用時序電路的設計方法,本文系統地研究了基于集成門電路的各種施密特電路,并發現了一些新的設計方案。PSPICE模擬證明所設計的電路具有理想的施密特電路特性。
-
關鍵詞:
- 施密特電路; 時序特征; 電路設計
Abstract: Based on the working characteristic of Schmitt circuits which have two detection thresholds to input signals, this paper proposes that Schmitt circuits have the same sequen-tial characteristic as flip-flops which are used as memory units. With the design procedure of sequential circuits, varieties of Schmitt circuits based on integrated gate circuits are systemati-cally investigated, and some new designs are found. PSPICE simulations prove that the circuits designed in this paper have ideal characteristic of Schmitt circuits. -
間閻,數字電了技術基礎(第三版),北京,高等教育出版社, 1989,320-332.[2]J.M.Rabaey,Digital Integrated Circuits,A Design Perspective,New York,Prentice-Hall Inter-national,Inc,1996,363-369.[3]杭國強,吳訓威.基于開關信號理論的電流控闡技術三值ECL施密特電路,電子學報, 1997,25[5),49-52.[4]Hang Guoqiang,Wu Xunwe,Research on ternary TTL Schmitt trigger,J.of Electronics(China),1998,15(1):35-42.[5]杭國強、吳訓威,基于開關厲號理論的控聞技術與二值ECL施密持電路,電路與系統學報,1998,3(2),15-20.[6]Shen Jizhong ,P.D.Tougaw,Design of symmetric ternary current-mode CMOS Schmitt inverter,Int.J.Electronics,1998,85(4),477-482.[7]吳訓威,趙小杰,脈沖電路中的變閥技術-施密持電路,電子與儀表技術, 1992,(2),1-5.[8]譚建生,李東,陳維良,數字電路與邏輯設計,北京,電子工業出版社, 1998,26l-263. -
