廣義網絡原理在電磁散射混合方法中的應用
THE APPLICATION OF GENERALIZED NETWORK PRINCIPLE TO HYBRID METHOD FOR ELECTROMAGNETIC SCATTERING
-
摘要: 本文提出了一種分析電大開槽目標電磁散射的混合方法。根據等效原理，將原目標的散射場分解為電大目標和槽縫散射場的疊加。前者用迭代物理光學法計算。對于后者，則先用時域有限差分法計算其導納矩陣，然后在口徑面上建立相應的廣義網絡模型，用網絡分析的方法求得槽縫的等效磁流，最后由互易定理推得散射場的表達式。數值結果證明了本文方法的準確性和高效性。
-
關鍵詞:
- 廣義網絡原理;時域有限差分法;混合方法;電磁散射
Abstract: A new hybrid method based on the generalized network principle is proposed to deal with the electromagnetic scattering of a large body with cracks.Using the equivalence theorem,the total scattered field can be regarded as the summation of two parts,the scattering of the large body and that of the cracks.The former is calculated by using iterative physical optical (IPO) method directly and the latter can be computed as follows:First,the admittance matrix of the crack is extracted by using the FDTD method,thus the generalized network representation of the crack can be set up on the aperture.Then the equivalent magnetic current on the crack aperture can be computed by network principles.According to the reciprocity theorem,the scattering from the crack can be obtained finally.Some numerical results show the feasibility and efficiency of the proposed method. -
Harrington R F,Mautz J R.A generalized network formulation for aperture problem.IEEE Trans.on AP,1976,AP-24(6):870-873.[2]Jeng S K.Scattering from a cavity-backed slit in a ground planeTE case.IEEE Trans.on AP,1990,AP-38(10):1523-1529.[3]黃河，聶小春，葛德彪．用FDTD提取槽口徑面上的等效電磁流.1998年計算物理學會計算電磁學研討會(SCEM98)論文集,四川成都:1998.7,78-81.[4]葛德彪,郭利強,李明之.用FDTD方法模擬穩態電磁散射時開關函數的應用.電子科學學刊,1997,15(4):441-443.[5]Obelleiro-Basteiro F,Rodriguez J L,Burkholder R J.An iterative physical optical approach for analyzing the electromagnetic scattering by large open-ended cavities.IEEE Trans.on AP,1995,AP-43(4):356-361.[6]Jin J M,Ni S S,Lee S W.Hybridization of SBR and FEM for scattering by large bodies with cracks and cavities.IEEE Trans.on AP,1995,AP-43(10):1130-1138. -
