天線模式項散射分析與天線RCS減縮
ANTENNA-MODE SCATTERING COMPONENT AND RCS REDUCTION
-
摘要: 天線的散射場是由結構散射場和模式散射場兩項組成。理論分析和實驗結果表明,后者對天線的雷達散射截面(RCS)的貢獻比前者要大得多,有效地克服模式散射場將會明顯地降低天線的RCS。本文提出了一種以克服面天線模式散射場達到降低天線雷達截面的模式項消去法減縮天線RCS技術,并在幾種天線模型上進行了實驗。實驗結果證明,這種技術減縮天線RCS的效果,不管在天線工作頻帶內還是頻帶外均可達到10～15dB。模式項消去法減縮技術是一種降低面天線RCS的新途徑,比其它減縮技術頻帶更寬,具有較好的工程適用性。
-
關鍵詞:
- 天線; 天線散射; 雷達散射截面; 隱身技術
Abstract: The radar cross-section (RCS) of antennas can be divided in to two parts, one is the common structural scattering component, another is the antenna-mode scattering component produced by antenna s re-radiation. Three kinds of antenna s RCS are discussed and the measured antenna s RCS reduction by the method of minimizing the mode scattering component are given. The experimental results show that the RCS reduction is about 10-15 dB both in the operating band and outside the band. The technique expressed in th... -
Hatrington R F. IEE Trans. on AP, 1963, AP-11(6): 595-596.[2]馮林,阮穎錚,雷平.電子科學學刊,1993, 15(5): 506-511.[3]馮林,雷平,阮碩錚.航空學報,1993, 14(11): 649-652.[4]阮穎錚,韓曉英,馮林,雷平.隱身技術,1990,6(1): 13-17.[5]阮穎錚.宇航學報,1990, 11(4): 94-100.[6]阮穎錚.隱身技術,1992, 14(1): 8-14.[7]Resister D D, Thiele G A, Eloe P W. Development of low RCS reflector antenna system. Proc. IEEE /AP-S, Seattle, USA: 1994, 2325-2328.[8]鄧書輝,阮穎錚.宇航學報,1991, 12(1): 84-88.[9]鄧書輝,阮穎錚.電子科技大學學報,1990, 19(5): 519-526. -
