一種級聯結構的高階全數字鎖相環
A HIGH ORDER ALL DIGITAL PHASE LOCKED LOOP WITH TANDEM STRUCTURE
-
摘要: 本文給出了一種高階全數字鎖相環的級聯結構形式,它通過結構簡單的全數字一階環的級聯來實現高階環路。它避免了通常的高階鎖相環中較復雜的數字濾波器,實現簡單,易于集成。本文介紹了級聯全數字二階環的原理和實現,對其性能進行了理論分析和計算機仿真,最后給出一個應用實例。
-
關鍵詞:
- 全數字鎖相環; 指針泄漏; 抖動
Abstract: A high order all digital phase locked loop with tandem structure is presented. A 2-order all digital PLL is implemented and its performance is verified by simulation. An example is given for SDH 2048Kb/s tributary recovery. Its performances are simulated and compared with the theoretical analysis. -
Loau Chii-Min, Wu Ji-Tsu. PHDPLL for SONET desynchronzer. GLOBECOM91, Phoenix, USA: 1991, 402-405.[2]ITU-T Recommendation G.783(Draft), Characteristics of synchronous digital hierarchy(SDH)[3]equipment functional blocks, 12.04.1997.[4]ITU-T Recommendation 6.823, The control of jitter and wander within digital networks which are based on the SDH, 1992.[5]張厥盛, 鄭繼禹, 萬心平. 鎖相技術西安:西安電子科技大學出版社, 1994，第七章, 第一節.[6]Hiknet Sari, et al. Cancellation of pointer adjustment jitter in SDH network. IEEE Trans. on Communications, 1994, COM-42(12): 3200-3207.[7]Kusyk R G, et al. Analysis of techniques for the reduction of jitter caused by SONET pointer adjustments. IEEE Trans. on Communications, 1994, COM-42(2/3/4): 2036-2050.[8]Transwitch Data Sheet, ADMA-El 2Mbit/s to TU-12 asynchronous mapper/desynchronizer, TXC-04002-MB, Ed.3A, August 1995. -
