注硅不摻雜半絕緣GaAs中的深能級缺陷
DEEP LEVEL DEFECTS IN Si-IMPLANTED LEC UNDOPED SI-GaAs
-
摘要: 用DLTS法對經兩步快速熱退火(RTA)后的注硅不摻雜SI-GaAs中的缺陷進行了研究。確定了激活層中存在著兩個電子陷阱組(以主能級ET1、ET2標記)及其電學參數的深度分布。在體內,ET1=Ec0.53eV,n=2.310-16cm2;ET2=Ec0.81eV,m=9.710-13cm2;密度典型值為NT1=8.01016cm-3,NT2=3.81016cm-3;表面附近,ET1=Ec0.45eV,NT1=1.91016cm-3;ET2=Ec0.71eV,NT2=1.21016cm-3,分別以[AsiVAs,AsGa]和[VAsAsiVGaAsGa]等作為ET1和ET2的缺陷構型解釋了它們?cè)赗TA過程中的行為。
-
關鍵詞:
- 注硅砷化鎵; 快速熱退火; 離子注入; 深能級
Abstract: DLTS technique has becn used to investigate (4 1012cm-2/30keV+5 1012cm-2/ 130keV)Si implanted LEC undoped SI-GaAs annealed by tow-step rapid thermal annealing (RTA) (970℃/9s +750℃/12s). Two electron traps ET1(Ec- 0.53 eV, 2.3 10-16cm2) and ET2(Ec-0.81eV, 9.710-13cm2) are detected. Furthermore, the noticeable variations of trap s concentration and energy level in the forbidden gap with the depth profile of defects induced by ion implantation and RTA processes have been observed, The [Asi VAsAsGa] and [VAsAsiVGaAsGa] are proposed as the possible atomic configurations of ET1,and ET2 respectively to explain their RTA behavior. -
R. Khanna, M. B. Das, Appl. Phys. Lett., 18(1986) 14, 937.[2] S. Dindo, et al., J. Electrochem. Soc., 132(1985)11, 2637.[3] S. Dhar, et al., J. Appl. Phys., 58(1985)11, 4216.[4] Y. J. Chan, M. S. Lin, J. Electron Mater., 15(1986)1, 31.[5] M. Kuzuhara, T. Nozaki, J. Appl. Phys., 59(1986)9, 3131.[6] A. Kitagawa, et al., J. Appl. Phys., 63(1988)2, 414.[2]黃迪惠,注硅半絕緣GaAs中深能級的DLTS研究及其計算機模擬分析,西安交通大學碩士學位論文, 1984年.[3]A. Zylbersztejn, Appl. Phys. Lett., 33(1978)2, 200.[9] J. L. Lee, et al., J. Appl. Phys., 65(1989)1, 396.[4]鄒元羲,汪光裕,莫培根,物理學進展,8(1988)4,432.[11] G. M. Martin, et al., Electron. Lett., 13(1977)7, 191.[12] W. Wesch, et al., J. Appl, Phys., 65(1.989)2, 519.[13] H. Y. Cho, et al., Appl. Phys., A48(1989)4, 359. -
