一種微波集成寬帶變?nèi)莨苷{(diào)諧體效應振蕩器的設計
A MICROWAVE INTEGRATED CIRCUIT DESIGN OF WIDEBAND VARACTOR TUNED BULK EFFECT OSCILLATOR
-
摘要: 本文利用電抗補償?shù)母拍顚纱?lián)體效應振蕩器進行電抗補償,使調諧帶寬增加。在C波段,相對調諧帶寬達10％以上;輸出功率大于30毫瓦;起伏小于3dB。給出了調諧帶寬的解析表達式和振蕩器電路的設計。 這種寬帶集成體效應振蕩器采用微帶和同軸相結合的結構。變并聯諧振為串聯諧振,頻率調整比較方便,在雷達和通信上得到了廣泛的應用。
-
關鍵詞:
Abstract: By the use of the concept of reactance compensation, the integrated series bulk effect oscillator, being compensated to increase the tuning bandwidth is reported. In C-band, the relative bandwidth is greater than 10 percent,the output power is greater than 30 mW, and the change of power is less than 3 dB. The analytical expression of tuning bandwidth and the design of oscillator circuit are given.The combined microstrip with coaxial line structure is adopted for the oscillator. Shunt resonance is changed into serier resonance. The integrated wideband bulk effect oscillator has a wide application in radar and radio communication. -
D. Cawsey, IEEE J. of SC, SC-5(1970), 82.[2]R. A. Gough and E. H. Newton, IEEE Trans. on ED, ED-20(1973), 863.[3]D. Lacombe, IEEE Trans. on MTT, MTT-20(1972), 555.[4]C. S. Aitchison and R. V. Gelsthorpc, IEEE J. of SC, SC-12(1977), 21.[5]馬均培,《電子對抗》技術文選,1981年,第7期,第1頁. -
