信號時域提取方法結合時域有限差分法分析傳輸線饋電的微波元件
ANALYSIS OF MICROWAVE COMPONENTS FED BY THE TRANSMISSION LINES WITH A METHOD OF SIGNAL EXTRACTION IN TIME DOMAIN IN COMBINATION WITH FDTD
-
摘要: 本文提出了一種信號時域提取方法,對于非色散傳輸線饋電的微波元件,利用這一方法,從時域模擬獲得的總場響應中提取饋線參考面上的時域入射波和反射波,進而得到其頻域特性。與傳統方法相比,它可以避免通過時域有限差分法直接求解入射波和反射波,因此可以減少計算時間和計算機內存。矩形微帶天線的數值模擬表明,這種方法的計算精度與傳統方法完全一致。
-
關鍵詞:
- 時域有限差分法; Fourier變換; 信號時域提取
Abstract: A method of signal extraction in time domain is proposed in this paper, by means of which, the time-domain incident wave and reflected wave on the reference plane of the feeder can be extracted from the total-field responses obtained from the time-domain simulation for the microwave components fed by the nondispersive transmission lines, furthermore, its frequency-domain parameters can also be acquired. By comparison with traditional methods, it can avoid to directly compute the time-domain incident wave and reflected wave using the finite-difference time-domain method, so computation time and storage can be reduced. The numerical simulations of rectangular microstrip antenna show that the computation precision of this method is the same as that of traditional methods. -
Yee K S. Numerical solution of intial boundary value problems inivolving Maxwells equations in isotropic media. IEEE Trans. on AP, 1966, 14(3): 302-307.[2]Reineix A, Jecko B. Analysis of microstrip patch antennas using finite difference time domain method. IEEE Trans. on AP, 1989, 37(11): 1361-1369.[3]Sheen D M, Ali S M, Abouzahra M D, Kong J A. Application of the three-domainsional finitedifference time-domain method to the analysis of planar microstrip circuits[J].IEEE Trans. on MTT.1990, 38(7):849-857[4]Ciampolini P, Roselli L, Stopponi G. Integrated FDTD and solid-state device simulation[J].IEEE Microwave and Guided Wave Letters.1996, 6(11):419-421[5]袁偉良,梁昌洪.波導不連續性的時域分析.西安電子科技大學學報,1997,24(4):453-458[6]Tsai H-S, York R A. FDTD analysis of CPW-fed folded-slot and multiple-slot antennas on thin substrates. IEEE Trans. on AP, 1996, 44(2): 217-225.[7]Mur G. Absorbing boundary conditions for the finite-difference approximation of the time-domain electromagnetic field equations. IEEE Trans. on EMC, 1981, 23(4): 377-382.[8]Piket-May M, Taflove A, Baron J. FD-TD Modeling of digital signal propagation in 3-D circuits with passive and active loads[J].IEEE Trans. on MTT.1994, 42(8):1514-1523[9]袁偉良,梁昌洪.FDTD分析微帶結構的一種饋源模型.1997全國微波年會會議(下冊),青島:1997,481-483. -
