高次模多注速調管的矩形雙間隙輸出腔的研究
Study of rectanglar double GAP output cavity of high mode multi-beam klystron
-
摘要: 研究一種工作在TM1202高次模的速調管矩形雙間隙輸出腔模型。運用Mafia三維電磁場計算軟件對模型進行計算機模擬,得出TM1202工作模式的頻率、特性阻抗和場分布。加工了TM1202高次模多注速調管雙間隙輸出腔模型并進行冷測試驗,測試結果與計算相符,并對計算和測試結果進行了分析。對該模型的研究為進一步研制工作在TM1202高次模多注速調管的高頻輸出系統(tǒng)提供了理論依據(jù)。Abstract: In this paper, a kind of rectanglar double gap output cavity model is studied. Si-ulation of the model with Mafia and ISFEL3D, three dimension electromagnetic field calculation software, is given. The frequency, characteristic impedance and field distribution of operating mode TM1202 obtained. The model is made and the test result of the model accords with the calculation. The analysis of the test and calculation is given. The study of this model has provided the foundation for further development of TM1202 high order high frequency output system of multi-beam Klystron.
-
丁耀根,彭鈞,多注速調管一種新型大功率微波放大器,電子科學學刊,1996,18(1),64-67.[2]R.H. Abrams, B. Leoush, A. A. Mondelli, R. R. Parker, Vacuum electronics for the 21 century,IEEE Trans. on Microwave Theory and Technology, 2001, 87(5), 65-66.[3]張益林,王定中等,5cm波段高次模多注速調管,中國電子學會真空電子學分會第十三屆學術年會,貴陽,2001,85-88.[4]丁耀根,朱允淑,多注速調管高次模諧振腔的研究,中國電子學會真空電子學分會第十屆學術年會論文集,北京,1995,77-80.[5]丁耀根,多注速調管雙間隙耦合腔特性的三維計算,中國電子學會真空電子學分會第十一屆學術年會論文集,青島,1997,122-124. -
