p-InP/TiPdAu體系的冶金行為和電學特性
METALLURGICAL AND ELECTRICAL CHARACTERISTICS OF p-InP/TiPdAu SYSTEMS
-
摘要: 正 (一)引言 近年來InP在光電和微波器件中的應用已引起廣泛重視。對InP的歐姆接觸和肖特基勢壘已有報道,這些結果表明,Bp較Bn大,n-InP的比接觸電阻較p-lnP的低。以InP為襯底的多層結構器件中,表面層有時是p-InP,因此研究p-InP與接觸金屬界面上的冶金行為和電學特性,對改善器件參數和提高器件的可靠性有實際意義。對p-InP與接觸金屬Pd,Mg/Ag,Au-Zn,Mg/Au,Pd/Ag的界面特性,已有用俄歇電子能譜(AES)和電子探針(EP)進行的研究結果
-
關鍵詞:
Abstract: The interdiffusion of p-InP/TiPdAu at interface has been investigated by Auger electron spectroscopy (AES). The surface morphology of heat treatment samples are observed. The specific contact resistance as a function of heat treatment temperatures for the p-InP/ TiPdAu systems is also given.It is found that the interdiffusion of Au, In, P occurs during the heat treatment of p-InP/TiPdAu. The Pd layer as a diffusion barrier plays an important role. The interdiffusion, morphology and specific contact resistance for heat treatment samples of p-InP/TiPdau have interconnection and strong dependence on each other. The TiPdAu layers are used as p-electrodes for InGaAsP/InP double heterojunction light emitting diodes. The p-electrode has good stability. -
E. H. Okelek et al., Solid-state Electronics, 24(1981),[2]G. Y. Robinson, Thin solid films, 72(1980), 129.[3]E. Kuphal, Solid-state Electronics, 24(1981), 69.[4]L. P. Erickson; Thin Sold Films, 64(1979), 421.[5]C. J. Jones et al.,J. Phys. D: Appl. Phys., 12(1979),941.[7]K.Fujiwara, Appl. Phys. Lett., 35(1979), 861.[8]水海龍等,半導體光電,1981年,第2期,第192頁.[9]水海龍等,電子學通訊,4(1982), 286.[10]張桂成等,發光與顯示,2(1982), 65. -
