大規模電路的島橋分析法
ISLAND-BRIDGE ANALYSIS FOR LARGE SCALE CIRCUIT
-
摘要: 對于一個n端子網絡,如果能夠得到每一端的端電流,那么這個子網絡就可解了。本文將一個大網絡分裂成P個子網絡,并在n端子網絡CCVS模型上提出了島和橋的概念,進而得到島方程,從而得到各子網絡的端電流。這種方法在分析大規模電路時,對于提高運算速度和節省計算機內存具有一定實際意義。Abstract: A subnetwork is able to be solved, if its terminal currents have been determined. In this paper, the concepts of island and bridge are presented, the CCVS model of n-terminal subnetwork is constructed, the island equations are deduced and then the currents of each subnetwork terminal are obtained. Using this method, the computing time and the memory space can be saved.
-
Wu F F. IEEE Trans. on CAS, 1976, CAS-23(12):706-713.[2]劉佩仙,等.電子學報,1989,17(4): 107-109.[3]韓躍新.電子學報,1988,16(4),52-58.[4]黃東泉,等.電子科學學刊,1992,14(1): 15-20. -
