低信噪比圖象邊緣提取的非線性方法
A NONLINEAR METHOD FOR EDGE DETECTION OF LOW SNR IMAGE
-
摘要: 針對低信噪比圖象的邊緣提取問題,本文提出了一種非線性方法,即利用大窗口平滑去噪性能強與小窗口提取邊緣性能好相結合的方法,此時采取大窗口濾波,小窗口中作非線性的微分算子求導。為了避免求導后閾值選取的盲目性,文中提出了一種噪聲引導的閾值確定準則,并根據這個閾值分割圖象。在大窗口濾波中,采用了二維卷積等于兩個一維卷積級聯的技術壓縮濾波器的存儲空間。最后對這種方法進行了性能評價,并且給出了實驗結果。
-
關鍵詞:
- 圖象處理; 邊緣提取; 非線性微分算子; 指數濾波器
Abstract: A nonlinear method for detecting the edge of low-SNR image is developed. This method adopts the filtering in large window to smooth the noise and the nonlinear differential operator in small window to detect the edges. A criterion of noise-guided threshold selection is introduced to segment the derivative image so that the threshold can be determined automatically. In large window s filtering, the technique of 2-D convolution implementation by two 1-D convolutions in series is taken to reduce the storage space of the filter. Finally, the performance of this method is evaluated, and experimental results are given. -
D. Marr, E. C. Hildretli, Theory of edge detection, Proc. R. Soc. London. B207, (1980), 187-217.[2]R. M. Haralick, IEEE Trans. on PAMI, PAMI-6(1984)1, 56-68.[3]W. E. L. Grimson, IEEE Trans. on PAMI, PAMI-7(1985)1, 121-127.[4]Shen, S. Castan, An optimal linear operator for edge detection, Proc, CVPR-86, Miami, (1986), 109-114.[5]J. S. Chen, IEEE Trans. on PAMI, PAMI-11(1989)2, 191-198.[6]V. Berzins, Computer Vision, Graphics and Image Processing 27(1984), 195-210.[7]Z. Xu, A further study on error probabilities of Laplacian-Gaussian edge detection, Proc. 8th ICPR, Paris, (1986), 601-603.[8]A, L. D. Beckers, Metingen van Parameters voor Niet-lineaire Objectgrootte-fillters in beelden, Ingenieur's[9]thesis, Department of Applied Physics, Delft University of Technology, Dutch, (1986), 601-603. -
