雙極模擬集成電路的參數統計性分析
THE PARAMETER STATISTICAL ANALYSIS FOR BIPOLAR ANALOGOUS INTEGRATED CIRCUIT DESIGN
-
摘要: 本文給出了實現雙極模擬集成電路參數統計相關性分析的步驟和方法,提出了含對稱參數分析的雙參數(BF,RS)統計分析方法。實例分析和對比表明,該方法適于模擬集成電路的分析和設計。
-
關鍵詞:
- 模擬集成電路; 參數統計分析; 相關性分析
Abstract: The method and procedure for realizing parameter statistical correlation analysis of bipolar analongous integrated circuits are given, and a statistical method of double parame-ters (BF, Rs) with some symmetrical parameters is suggested. Based on the comparision and analysis of the circuits, it is shown that the method can be used to analyse and design bipolar analogous integrated circuits. -
D. A. Divakar, IEEE J. of SC, SC-12(1977)10, 552-559.[2]P. Balaban, IEEE Trans. on CAS, CAS-22(1975)2,100-108.[3]S. Inohira, IEEE Trans. on CAD, CAD-4(1985)4, 621-627.[4]J. Logan, Bell Syst. Tech. J., 50(1971)4, 1105-1174.[5]郝躍,姚立真等,電子科學學刊,10(1988)6,501-506. -
