基于光探針的超高速波形數字化測試系統的應用
APPLICATION OF ULTRA-HIGH SPEED WAVEFORM DIGITIZED SYSTEM TO IC BASED ON LASER PROBE
-
摘要: 介紹了基于光探針的超高速波形數字化系統的結構。采用倍頻移相掃描法測量了高速集成電路芯片各級的功能。分析了芯片故障產生的原因和光探針測量的特點。
-
關鍵詞:
- 光探針; 電光采佯; 集成電路芯片
Abstract: This paper introduces the construction of the ultra-high speed waveform digitized system based on laser probe. The functions of different stages of the high-speed dynamic divider circuit chip are measured with the double-frequency phase sweeping technique. A detail analysis about the chip failure and the characteristics of laser probe measurement is given. -
Kolner B H, Bloom D M. Electronic sampling in GaAs integrated circuits. IEEE J. of QE., 1986,QE-22(1): 79-93.[2]Duvillaret L, Lourtioz J M, Chusseau L. Absolute voltage measurements on Ⅲ-V integrated circuits by internal electro-optic sampling[J].Electron. Lett.1995, 31(1):23-24[3]田小建,衣茂斌,等.倍頻移相掃描電光采樣測量.紅外與毫米波學報,1997,16(3):190-192.[4]Mitsuru S, Tadao N. An automated electro-optic probing system for ultra-high-speed ICs. IEEE Trans. on Instrum. Meas., 1994, IM-43(6): 843-847. -
