部分填充雙各向異性介質的圓柱形波導中混合模特性研究
STUDY ON THE CHARACTERISTICS OF HYBRID MODES IN CIRCULAR WAVEGUIDES PARTIALLY FILLED WITH BIANISOTROPIC MEDIUM
-
摘要: 本文首先引入一種新型雙各向異性波導結構;給出了這類復雜波導中橫向場分量的縱向場表示式以及縱向場分量滿足的一組耦合模方程;重點分析了具有不同電磁參數的雙各向異性介質中心加載時,金屬圓柱形波導中混合模的分裂效應,色散特性和場分布。結果表明,由于多個電磁參數的引入,雙各向異性波導具有一般各向異性和雙各向同性波導結構所沒有的新奇特性。Abstract: A new kind of bianisotropic waveguide structure is introduced. In such complex waveguide, the transverse field components can also be expressed in terms of their longitudinal electric and magnetic fields, and a set of coupled mode equations is derived. The bifurcation effect, dispersion characteristics as well as field distribution of hybrid modes in bianisotropic central loaded-metallic circular waveguide are investigated. The numerical results show that because of the introducing of many electromagnetic parameters, bianisotropic waveguides possess some features, which can be used to design novel microwave, millimeter wave and optical devices.
-
Paul D K, Shevgaonkar R K. Radio Science, 1981. 16(4):525-533.[2]Okoniewski M, et al. J. Electromagnetic Waves and Applications, 1992, 6(11): 1561-1579.[3]Lu M, Fejer M M. J. Opt[J].Soc. Am. A.1993, 10(2):246-261[4]Monzon J C. IEEE Trans. on AP. 1990, AP-38(2): 227-235.[5]Tretyakov S A,et al. J. Electromagnetic Waves and Applications, 1992. 6(10): 1393-1411.[6]Graglia R D, et al. Electromagnetics, 1991, 11(2):193-208.[7]Tsalamengas J L. IEEE Trans. on MTT. 1992, MTT-40(9): 1870-1877.[8]Olyslaget F, Zutter D D. Radio Science, 1993, 28(5):937-946.[9]Svedin J A M. IEEE Trans. on MTT. 1990, MTT-38(10):1488-1496. -
