襯底熱空穴導致的薄柵介質經時擊穿的物理模型研究
Study on substrate hot-hole-induced physical model of TDDB in thin gate dielectric
-
摘要: 該文定量研究了熱電子和空穴注入對薄柵氧化層擊穿的影響,討論了不同應力條件下的閾值電壓變化,首次提出了薄柵氧化層的經時擊穿是由熱電子和空穴共同作用的結果,并對上述實驗現象進行了詳細的理論分析,提出了薄柵氧化層經時擊穿分兩步。首先注入的熱電子在薄柵氧化層中產生陷阱中心,然后空穴陷入陷阱導致薄柵氧擊穿。
-
關鍵詞:
- 薄柵氧化層; 經時擊穿; 襯底熱空穴（SHH）; 模型
Abstract: The roles of hot electrons and holes in dielectric breakdown of the thin gate oxide have been quantitatively investigated in this paper, The changes of threshold voltage have been discussed under different stress conditions. This paper is the first report that points out the cooperation of hot electrons and holes is essential for the time dependent dielectric breakdown in thin gate oxide. A detailed theory analysis is made and a two-step models of thin gate oxide is presented. The first step is injected hot electrons create trap centers in thin gate oxide, and the second step is thin gate oxide breakdown induced by hole trapping. -
T. H.Distefano, Delectric breakdown induced by sodium in MOS structures. ,J. Appl. Phys.,1973, 44(1), 527-530.[2]J.J. Tzou, C. C. Yao, R. Cheung, H. Chan, Temperature dependence of charge generation andbreakdown in SiO2, IEEE Electorn Device Lett., 1986, 7(7), 446-448.[3]X. Klein, Breakdown mechanism of thermal grown silicon dioxide at, high electric fields. ,J. Appl.Phys., 1988, 63(3), 970-972.[4]1. C. Chen, C. Hu, Electric breakdown in thin gate and tunneling oxide, IEEE Trans. On ElectronDevices,1985,32(2),413-422[5]Eli. harari, Dielectric breakdown in electrically stressed thin films of thermal SiO2, J. Appl.Phys.,49(4), April, 1998, 2478-2489.[6]D. ,J. Dumin, A model realiating wearout to breakdown in thin oxides, IEEE Trans. on Electron Devices. 1994, 41(9), 1570-1580.[7]P.p. Apte, Correlation of trap generation to charge-to -breakdown (Qbd): A physical-dama1e model of dielectric breakdown, IEEE Trans. on Electron Devices, 1994, 41(9), 1595-1602.[8]劉紅俠,郝躍,薄柵氧化層相關擊穿電荷研究,半導體學報,2000,21(2),146-150. -
