寬帶天線開關管頻率特性的理論計算
THEORETICAL CALCULATION OF BANDPASS CHARACTERISTICS OF WIDE-BAND TR TUBE
-
摘要: 本文從理論上計算了天線開關管(又稱TR管)的頻率特性,理論模型是諧振元件的集總參數的并聯,逐級進行電納的變換。數值計算是采取FORTRAN語言程序在向量計算機上進行的。計算曲線與實驗結果比較符合。計算曲線對于寬帶TR管的頻帶設計提供了有益的參考。
-
關鍵詞:
- 天線開關管; 微波濾波器; 向量計算
Abstract: The Bandpass characteristics of microwave duplexer TR tube have been calcu-lated theoretically. The theoretical model is that the multiple resonant elements with lumped parameter are shunted, and then the susceptances of these element are transposed step by step. Numeral calculation have been carried out on vector computer with FORTRAN language. Numerical results are in agreement with experimental ones. These calculated results will pro-vide useful rcfcrence for designing wide-band TR tube. -
L. D. Smulin, C. G. Mantgomery, Microwave Duplexer, McGraw-Hill, (1948), Chap. 3.[2]A. Kraszewski, Microwave Gas Discharge Device, London[3]Iliffe Books Ltd, (1967), Chap. 4.[4]И.В.Лебедев,Резонансние Разрядники Антенных Переклюцателей,Советское Радио,Москва, (1976), Глава 3[5]電子管手冊編輯委員會主編,天線開關管設計手冊,國防工業出版社,1983年.[6]T. S. Chen,RCA Rcv., 15(1954) 6,204-229. -
