用一種非晶軟磁薄膜為芯制成的磁探測器的分辨率研究
STUDY OF THE MAGNITEC RESOLUTION OF A MAGNETIC DETECTOR MADE OF AMORPHOUS SOFT MAGNETIC FILM CORES
-
摘要: 以兩根非晶軟磁薄膜條(0.0251.060mm3)為芯繞成差分復繞初級和次級線圈的探測器具有良好的磁敏感特性和溫度特性。試驗表明,這種非晶軟磁薄膜為芯的磁探測器次級輸出的倍頻信號電平與外界磁場具有良好的線性關系。其磁分辨率可達10-1010-11T,而且在－40℃120℃的溫度范圍內,溫度系數為0.05﹪/℃。其磁分辨率隨芯的長度變長而變高,而與芯的厚度和寬度在一定的范圍內基本無關。這種探測器同多晶軟磁薄膜為芯的探測器相比較,具有體積小,穩定性好,耐用及溫度特性好的優點。
-
關鍵詞:
- 磁探測器; 非晶軟磁薄膜; 磁分辨率
Abstract: The magnetic detector made of aamorphous soft magnetic film cores has better characteristics. Experimental results indicate that the detector has a good linear relation between the double-frequency single voltage output and the magnetic field, a magnetic resolution of 10-10--10-11T, and a temperature coefficient of 0.05%/℃ between －40--120℃, The magnetic resolution of the detector increases with lengthening the core, but it is independent of the width and thickness of the core in a certain range. This kind of detector compared with the detector using polycrystal soft magnetic thin film has many advantages, such as smaller side, better durability, stability and temperature characteristic. -
F. Primdahl, Sci. Instrum., 24(1979)4, 241-245.[2]P. Dyal et al., IEEE Trans. on GE, GE-8(1970)4, 203-215.[3]M. H. Acuna, IEEE Trans. on MAG, MAG-8(1974), 519-523.[4]孫玉魂等編著,金屬軟磁材料及其應用,冶金工業出版社,北京,1974年,第一章第三節,第二章第三節,第十二[5]章.[6]S. H. Noble, Proc. IEEE; 40(1952), 99-106. -
