天線陣輻射圖零點控制理論導論
ANTENNA ARRAY PATTERN NULL-STEERINGA THEORETICAL INTRODUCTION
-
摘要: 天線陣輻射圖型強制零點控制,由于對定向干擾抑制的有效性,已成為天線陣輻射圖型綜合理論中心課題之一。本文圍繞著這個課題,對三維天線陣輻射圈的零點控制進行了研究,它包括:用矢量空間方法,分析了多重零點控制的基本關系;根據零點本身的擴展性,引入了零域的概念,提出了多重強制零域的生成方法;導出了多重零點控制輻射圖型的分解公式;揭示了由主波束和多個零點強制波束合成多重強制零點輻射圖型的基本規律;給出了數值結果并進行了討論;把這一分解原理與自適應成零天線陣輻射圖型進行了類比。
-
關鍵詞:
Abstract: Antenna array pattern null-steering is one of the important current topics in array synthesis theory, because it is very effective in suppressing interfering signals. Thus the problem of forming nulls in the radiational pattern of three-dimentional arrays is discussed. This paper discusses the following aspects of the said arrays: The essential relations of forming multi-nulls are analysed by the method of vector space; The method of forming multi-null regions is presertted by the concept of null region in terms of the extended property of null itself the beam-resolvent formulation of radiational pattern of multi-null steering is derived; numerical results are included and discussed. The beam-resolvent formulation is analogous to the one of adaptive arrays. -
P. L. E. Uslenghi, Electromagnetic Scattering, Academic Press Inc.,1978.[2]D. E. N. Davies, IEEE Trans. on AP, AP-15(7967), 296.[3]C. Drane Jr. and J. Mcilvenna, Radio and Electron Eng., 39(1970), 49.[4]J. Mcilvenna and C. Drane, Jr., Radio and Electron Eng., 41(1971), 569.[6]D. E. N. Davies and Mrs. M. Rizk, Electronics Letters, 13(1977), 669.[7]D. E. N. Davies, M. S. As Rizk, IEE Conference Publication, No. 169, Antennas and Propagation,(1978), p. 60.[8]J. Mcilvenna et al., AD-A031, 153 (RADC-TR-76-183).[9]B. D. Steinberg.[J].Principles of Aperture and Array System Design, John Wiley Sons Inc.1976,:-[12]E. Kreysizig, Advanced Engineering Mathematics, John Wiley and Sons. Inc.,(1972), Chapter 6.[13]劉振威,電子學通訊,191979,118.[15]W. F. Gabriel, Proc. IEEE, 64(1976),239.[16]M.D.Windram, et al., IEE Proc. 127,F(1980), 243.[17]劉振威,電子學通訊,3(1981), 137. -
