空間波法測地物介電常數的反演方法
INVERSE FORMULATIONS FOR PERMITTIVITY MEASUREMENT OF GROUND MATERIALS USING SPACE-WAVE METHOD
-
摘要: 空間波法適合于測量大面積目標的介電常數,所以是測量地物微波介電特性的一種較好的方法。這種方法從測量數據反演復介電常數要用菲涅爾公式,如果測量數據包含相位信息,則反演是簡單的;但是如果測量數據只是幅度,則反演過程需要求解一個二次非線性方程組,以往都采用近似的數字迭代求解,迭代過程對初值和測量數據本身都太敏感,解的存在性、唯一性和穩定性難以判定。本文給出了嚴格的解析反演法,并證明了解的唯一性和反演結果對測量誤差的敏感性。Abstract: The space-wave method, suitable for extended surface targets, is a preferable method for permittivity measurement of ground materials at microwave frequencies. The inversion of permittivity from the measured data, which is established on using the Fresnel reflection coefficients, is easy if the measurement includes phase information. However, if the measured quantities are just the amplitudes of the reflected waves, the inversion will be much complicated by solving a quadratic nonlinear equation set, and so far only numerical iterative approaches have been reported in the literature. Unfortunately, the iterative process is highly unstable because of the extremely sensitivity of the inverse algorithms to the measured data and even to the iterative initial values. In the present work, analytical inverse formulations are presented which will give a unique inverse result if it does exist for a set of measured data. Error sensitivity of the inversion to the measurement errors are performed, as well.
-
張俊榮,張德海,王麗巍.微波遙感中的介電常數.遙感技術與應用,1994,9(2):30-43.[2]張俊榮,王麗巍,張德海.植被和土壤的微波介電常數.遙感技術與應用,1995,10(3):40-45.[3]Bernard P A, Cautray J M, Measurement of dielectric constant using a microstriP ring resonator,[4]IEEE Trans.on MTT,1991,MTT-39(3):592-595.[5]陳志雨,李安萊,周冬青.空間波與長試樣法測量介電常數的結果與對照.遙感學報,1997,1(l):40-45.[6]Staebell K F, Misra D, An experimental technique for in vivo Permittivity measurement of ma-[7]terials at microwave frequencies,IEEE Trans.on MTT,1990,MTT-38(3):337-339.[8]康士峰,孫芳,羅賢云,等.地物介電常數測量和分析.電波科學學報,1997, 12(2): 161-168.[9]黃揚,楊習榮,耿淮濱.土壤含水量與其微波反射特性關系的研究.環境遙感,1986, 1(2): 101-106.[10]張俊榮,張德海,王麗巍,等.微波遙感典型地物介電常數實地測量.電子科學學刊,1997, 19(4): 566-569.[11]Ulaby F T, Moore R K, Fung A K. Microwave Remote Sensing, VOl.II, Massachusetts: Addison-Wesley Pub. Co., 1982, 929-931, 956-960.[12]Chen Z Y, Zhou D Q. Dual polarization and phase method to detect permittivity of media in half-space, Proc. of Asian-Pacific Microwave Conference, Hongkang: Dec. 1997, 893-896. -
