差值感應法測量電視偏轉線圈的空間磁場
THE MEASUREMENT OF SPACE MAGNETIC FIELD OF TV DEFLECTION YOKE USING A DIFFERENCE INDUCTION METHOD
-
摘要: 本文扼要地介紹了測量磁場的各種電測方法并作了比較。詳細論述了測量偏轉線圈磁場的原理及方法。提出了三探針的測場機構及切實可行的測量裝置。測出了電視偏轉線圈的磁場參數曲線H0(z)、H2(z)及H4(z)。
-
關鍵詞:
Abstract: In this paper some methods for measuring magnetic fields are described coneisely and a comparison between these methods is made. The general theory and experiment-al method for measuring the TV deflecting magnetic field are given in detail. A practical measuring set up is presented. The curves of the magnetic field parameters H0(z), H2(z) and H4(z) are shown. -
G. Trenkler, Messent-priifen (Bonn), 8(1972), 705.[2]J. Kaashoek, Philips Res. Rept. Suppl., 23(1968), 1.[3]R. Vonk, Philips Tech. Rev., 32(1971), 61.[4]J. Kaashoek, Mullard Tech. Commun. (GB), 13(1974), 15.[5]I. Rezanka, Czech, J. Phys. B, 13(1963), 545[7]J. Haantjes and G. J. Lubben, Philips Res. Rept., 12(1957), 46.[8]Y. Yokota, IEEE Trans. on CE, CE-25(1979), 91. -
