非對稱電偶極在地層中的熱效應解析解
Analytical solution about heating effects of a non-symmetrical dipole in lossy media
-
摘要: 用近似法分析了有耗媒質中非對稱電偶極的激勵場,得到一個場和焦耳熱的簡單的解析表達式。與傳統的對稱型半波振子公式相比較,其下端導體的電流分布表達式相同,當下端導體為四分之一波長時激勵近場表達式相近。結合典型儲油層給出一些計算結果,對電磁波采油技術有參考價值。
-
關鍵詞:
- 非對稱電偶極; 熱效應解析解; 電磁波采油
Abstract: An approximate method is used to analyse the excited fields with a non-symmetrical dipole in lossy media and simple analytical expressions about the fields and joule heat are obtained. These expressions are compared with the formulas of traditional symmetrical half-wave dipole. Some calculated results are given for a typical oil reservior, which will be useful for the electromagnetic wave oil recovery technique. -
A. Chakma, K. N. Jha, Heating oil recovery from thin pay zone by electromagnetic heating, SPE 24817, 1992, 525-534.[2]M.Y. Xia, Z. Y. Chan, Attenuation predictions at extremely low frequencies for measurement while drilling electromagnetic telemetry system, IEEE-GRS, 1993, 31(6), 1222 1228.[3]Chen Zhiyu, Xia Mingyao, The frequency property of buried non-symmetrical dipole, International Journal of Electronics, 1993, 75(4), 783-793. ［4］R.W.P. King, K. IIZUKA, The complete electromagnetic field of a half-wave dipole in a dissipative medium, IEEE-AP, 1963, 11(5), 275-285. -
