Ka波段Gunn鎖相源的研究
STUDY OF Ka-BAND GUNN PHASE-LOCKED SOURCE
-
摘要: 本文對Ka波段鎖相源作了分析和研究,探討了毫米波鎖相環路的穩定性和相位超前補償問題。采用雙鎖相環路研制了腔穩偏壓調壓控振蕩器(VCO)、高次倍頻器、低相噪微波鎖相源等關鍵部件,采用了表面安裝技術(SMT)和高密度組裝技術,使研制的毫米波鎖相源具有小型化、低相位噪聲、高穩定度等特點。
-
關鍵詞:
- 毫米波; 鎖相環; 相位噪聲; 頻率穩定度
Abstract: A Ka-band phase-locked source (PLS) is analyzed and studied in detail. The stability of the millimeter PLL and the theory of phase compensation are discussed. In the practical scheme, the double PLL is applied, and the key components, such as the stable-cavity bias-tuned VCO, high-order multiplier and low phase-noise microwave PLL are developed. The SMT and high density assembly assembly technology are utilized in structure. Finally the millimeter PLS possesses features of miniaturization and low phase noise and high frequency stability. -
Carlstron J E. IEEE Trans on MTT. 1985, MTT-33(7): 127-129.[2]Bester M. International Journal of Infrared and Millimeter Waves. 1986, 7(1): 206-208.[3]劉紹球等.控制系統工程,北京,電子工業出版社,1985, 154-167.[4]Li Dunfu, Yun Xiaohua. Stability for 8mm Phase Locked Souce, International Conference on Milimeter Wave and Far-infrared Technology. Beijing: June 19-23, 1989, 606-609.[5]Robins W P. Phase Noise in Signal Sources, Pereprinlisinlis Ltd, London: UK. 1982, 93-133. -
