平板介質波導不連續性問題的有限元分析
FINITE-ELEMENT ANALYSIS OF PLANAR DIELECTRIC WAVEGUIDE DISCONTINUITIES
-
摘要: 本文應用有限元、模匹配和多模網絡相結合的方法,分析了平板介質波導不連續性結構的散射及輻射特性。與常規的從場源關系出發來分析輻射問題的方法不同,本文方法從求解介質波導結構的色散特性入手,從散射的角度將輻射問題轉化為表面波和空間波的傳輸問題,從而使分析過程得到了很大的簡化。
-
關鍵詞:
- 有限元; 模匹配; 多模網絡; 平板介質波導
Abstract: The finite element method is combined with the mode-matching method and the multi-mode network theory to analyze the scattering and radiation characteristics of a class of planar dielectric waveguide discontinuities. Unlike the conventional method to treat the radiation as a source-field problem, in the present approach, the dispersion characteristics of dielectric guidedwave structures are calculated first, and then the radiation problem is transferred to the propagation problem of a series of surface-waves and space waves from the viewpoint of scattering, thus the analysis is tremendously simplified. -
Rozzi T E. Rigorous analysis of the step discontinuity in a planar dielectric waveguide. IEEE Trans. on MTT, 1978, MTT-26(10): 738-746.[2]Rozzi T E, et al. Finite element analysis of interacting step discontinuity in a planar dielectric waveguide. IEEE Trans. on MTT, 1979, MTT-27(4): 303-309.[3]Suzuke M, Kosshiba M. Finite element analysis of discontinuity problems in a planar dielectric waveguide[J].Radio Science.1982, 17(1):85-91[4]Hirayama K, Kosshiba M. Analysis of discontinuities in an open dielectric slab waveguide by combination of finite and boundary elements. IEEE Trans. on MTT, 1989, MTT-37(4): 761-768.[5]Hirayama K, Kosshiba M. Numerical analysis of arbitrarily shaped discontinuities between planar dielectric waveguide with different thickness. IEEE Trans. on MTT, 1990, MTT-38(3): 260-264.[6]Peng S T, Oliner A A. Guidance and leackage properties of a class of the open dielectric waveguides. Part I: Mathematical formulation, IEEE Trans. on MTT, 1981, MTT-29(9): 843-855.[7]Xu Shanjia, Peng S T. Reflection analysis for planar surface wave antennas with different tapering profiles. Int. J. of Infrared and mm Waves, 1995, 16(12): 1122-1135.[8]Shigesawa H, Tsuji M. Mode propagation through a step discontinuity in dielectric planar waveeuide. IEEE Trans. on MTT, 1986, MTT-34(2): 205-212. -
