采用脈沖寬度調制技術實現人工神經網絡
The implementation of artificial neural networks using pulse width modulation technique
-
摘要: 該文提出了一種采用脈沖寬度調制(PWM)技術實現的人工神經網絡(ANN),神經網絡的權值采用數字存儲器存儲,突觸電路由開關組成,電容積分電路和電流采樣保持電路完成輸入信號和權值信號的乘加運算,輸出采用雙電流鏡。電路結構簡單,易于集成,可用于構成前饋網絡,如實現異或運算的人工神經網絡。Abstract: An Artificial Neural Network (ANN) is proposed which is implemented through Pulse Width Modulation (PWM) technique. The weight of the neural network is stored in digital memory, while the synapse circuits are composed of switches. The capacitor integral circuits and the current sample/hold circuits are used to implement the Weighted summation Operation (WSO) that are required in the realization of a general ANN. This circuit is easy to be integrated because of its simple structure, which could be used to construct the feed forward neural networks, for example, to implement ANN for an XOR function.
-
Yasuhiro Ota, B. M. Wilamowki, Analog implementation of pulse-coupled neural networks, IEEE Trans. on Neural Networks, 1999, 10(3), 539-544.[2]R. Coggins, M. Jabri, B. Flower, S. Pickard, A hybrid analog and digital VLSI neural network for intracardiac morphology classification, IEEE J. of Solid State Circuits, 1995, 30(5), 542-550.[3]王智,陳瓊,鄭啟倫,用BiCMOS工藝實現的閾值神經元電路,華南理工大學學報(自然科學版),1999,27(12),11-15[4]陳瓊,鄭啟倫,神經網絡系統硬件實現的研究進展,電路與系統學報,2000,(1),48-51.[5]王若愚,鄭啟倫,黃貫光,一種基于符號邏輯的神經元模型和電路實現,電子科學學刊,1999,21(1),55-59[6]王伶俐,宋靈貴,吳桂初,陳偕雄,基于雙向電流型CMOS電路的譜綜合,電子科學學刊,2000,22(2),311-315.[7]張玉浩,等譯,模擬集成電路設計一電流模法,北京,高等教育出版社,1996,157-212,398-408. -
