VHDL高級綜合中的多目標工藝映射方法
A METHODOLOGY OF TECHNOLOGY MAPPING FOR MULTI-TARGET IN VHDL HIGH LEVEL SYNTHESIS SYSTEM
-
摘要: 從國內情況看,高級綜合系統的目標,即后端CAD版圖工具可分為兩大類。一類只能接收門級網表;而另一類其單元庫較為完備,往往能接收較大顆粒度的宏單元。針對這種情況,本文研究高級綜合結果與后端工藝的銜接問題。提出多目標多層次工藝映射(MLTMMT)策略,旨在與多種工藝銜接。解決實現該策略的有關問題:(1)給出多目標工藝映射方法的形式化描述;(2)給出在多個層次上的多目標工藝映射方法;(3)分析研究多種工藝庫,提出一種面積和延時的線性模型;(4)給出RTL通用元件集;(5)建立多種工藝VHDL模擬模型。所實現的系統已完成與三種工藝銜接,驗證了本文工作。Abstract: This paper is focused on the research of connecting the HLS(High Level Synthesis) result to the technology of IC,To connect to deferent technology, a tactics of MLTMMT(Multi Level Technology Mapping for Multi-Target)is proposed, All key points are researched which include: (1)giying the formal descirption of the technology mapping for multi-target; (2)giving the method of MLTMMT; (3)analyzing and researching many technology libraries,presenting a lineal model of area and delay of the technology cells: (4)giving the set of the general RTL components; (5)building the VHDL simulation model in different technologies.The system has been connected To 3 kinds of IC prodaction line: and this verifies the theory and method.
-
劉明業，等．專用集成電路(ASIC)高級綜合理論．北京：北京理工大學出版社，1998，179-246．[2]馬聰，劉明業，等．VHDL高級綜合與底層物理設計的銜接，電子學報，1998，26(2)：71-73.[3]Chaadhuris，Quayle M．Using conmplex sequential models in RTL synthesis Proc．Ninth Annual IEEE International ASIC Conference and Exhibit Rochester,NY,USA：23-27，Sept．1996，139-142[4]Chaudhary K，Pedram M Computing the area versus delay trade-off curves in technology mapping IEEE Trans．On Conp.-Aided Des．Of Integr.Circuits Syst．1995，14(12)：1480-1489.[5]Shih-Chien Chang，Marek-Sadowdka M. Technology mapping for TLU FPGAs based on decomposition of binary decision diagrams，IEEE Trans，on Comp.-Aided Des．Of Integr．Circuits Syst 1996，15(10)：1226-1236．[6]Jha P K，Durt N D．High-level library mapping for arithmetic components，IEEE Trans．On VLSI Syst．1996，4(2)：157-169。[7]馬聰、劉明業，等．高級綜合中工藝單元VHDL模擬模型的建立方法．計算機輔助設計與圖形學學報，1998，10(增刊)：143-147. -
