波數字濾波器傳輸特性的計算機輔助分析
COMPUTER-AIDED ANALYSIS FOR TRANSFER CHARACTERISTIC OF WAVE DIGITAL FILTER
-
摘要: 正 1.引言 波數字濾波器(以下簡寫為WDF)因具有低靈敏度性質,可用較短的系數字長加以實現而得到重視。一般的數字濾波器的設計往往是先尋求其傳輸特性表達式,然后考慮實現的結構。WDF則不然,它直接引用模擬濾波器的結構,將模擬元件及其聯接方式變換到數字域即形成WDF的數字結構,而其在數字域上的傳輸特性則常是待求的。關于
-
關鍵詞:
Abstract: An approach for finding the transfer characteristic of wave digital filter is presented and a general computer program is developed. The program can be used to analyse the quantification effect of different coefficient word-lengths to the transfer characteristic of wave digital filter, thus it is possible to make a reasoriable choice of coefficient Word-length jn order to take account of the economics as well as the technical specification in the hardware implementation of wave digital filter. -
A. Fettweis, Arch. Elck.bertragung., 25(1971), 79-89.[2]K. Renner, and S. C. Gupta, IEEE Trans. on CT,CT-20(1973), 555-67.[3]A. Antoniou, Digital Filter: Analysis and Design, MeGraw-Hill Book Co., New York, 1979, ch. 12.[4]A Fettweis, H. Levin and A. Sedlmeyer, Int. J. Circuit Theory and Applications,2(1974), 203-11.[5]K. Owcnier, IEEE Trans. on CAS, CAS-30(1983), 750-7.[6]A. Fettweis and K. Merkotter, IEEE Trans. on ASSP, ASSP-23(1975), 516-25. -
