多輸出端電流模式全差分積分器實現帶通濾波器的方法及仿真

江金光,  何怡剛

江金光, 何怡剛. 多輸出端電流模式全差分積分器實現帶通濾波器的方法及仿真[J]. 電子與信息學報, 2003, 25(12): 1725-1728.
引用本文: 江金光, 何怡剛. 多輸出端電流模式全差分積分器實現帶通濾波器的方法及仿真[J]. 電子與信息學報, 2003, 25(12): 1725-1728.
Jiang Jin-guang, He Yi-gang. Realization and Simulation of Band-Pass Filter Based on MCDI[J]. Journal of Electronics & Information Technology, 2003, 25(12): 1725-1728.
Citation: Jiang Jin-guang, He Yi-gang. Realization and Simulation of Band-Pass Filter Based on MCDI[J]. Journal of Electronics & Information Technology, 2003, 25(12): 1725-1728.

多輸出端電流模式全差分積分器實現帶通濾波器的方法及仿真

Realization and Simulation of Band-Pass Filter Based on MCDI

  • 摘要: 該文提出了利用低電壓多輸出端電流模式全差分積分器(MCDI)設計實現連續時間電流模式濾波器的方法.分析并模擬了MCDI及所提出的濾波器的特性,應用3.3V,0.5m,CMOS工藝參數仿真得到的二階帶通濾波器功耗僅為0.6mW左右,且其中心頻率可在很寬的范圍內調控.此外,這種濾波器還具有結構簡單、對稱性好、失真小等優點,適于全集成.
    Abstract: A methodology to realize continuous-time current-mode filters using low-voltage Multi-output Current-mode Differential Integrator (MCDI) is presented. At first, the char-acteristics of MCDI and the proposed filters which employ MCDI are analyzed and simu-lated. Simulation results not only predict second-order band-pass filter dissipating as little as 0.6mW power or so with 3.3V power supply using 0.5/xm CMOS technology, while the center frequency of which can be tuning in a wide range, but also with the advantages such as simple structure, good symmetry, low harmonic distortion, and suitable for integration.
    • HTML全文
  • Lee Sang-soo, Zele R H, Allstot D J. Guojin Liang. A continuous-time current-mode integrator.IEEE Trans. on Circuits and Systems, 1991, 38(10): 1236-1238.[2]Wu J, EI-Marsy E. Current-mode ladder filters using multiple output current conveyors. IEE Proc. Circuits, Devices. Syst. 1996, 143(4): 218-222.[3]Tsividis Y P. Integrated continuous-time filter design-An overview[J].IEEE J. of Solid-State Circuits.1994, 29(3):166-176[4]Lee Sang-soo, Zele R H, Allstot D J, Guojin Liang. CMOS continuous-time current-mode filters for high-frequency applications[J].IEEE J. of Solid-State Circuits.1993, 28(3):323-329[5]Zele R H, Allstot D J, Fiez T S. Fully balanced CMOS current-mode circuits[J].IEEE J. of SolidState Circuits.1993, 28(5):569-575[6]Zele R H, Allstot D J. Low-voltage fully differential switched-current filters[J].IEEE J. of SolidState Circuits.1994, 29(3):203-209[7]Fiez T S, Allstot D J. CMOS switch-current ladder filters[J].IEEE J. of Solid-State Circuits.1990,25(6):1360-1367[8]Khoury J M. Design of a 15-MHz CMOS continuous-time filter with on-chip tuning[J].IEEE J. of Solid-State Circuits.1991, 26(12):1988-1997[9]Un-Ku Moon, Bang-Sup Song. Design of low-distortion 22-kHz fifth-order Bessel filter[J].IEEE J.of Solid-State Circuits.1993, 28(12):1254-1264[10]趙錄懷,邱關源.用對數域電流模式積分器實現的高頻集成濾波器.電路與系統學報,1996,1(3):32-37.[11]趙錄懷,邱關源.一種新型電流模式連續時間波有源濾波器.電子學報,1997,25(4):108-110.[12]趙錄懷,邱關源.電流模式高階濾波器設計的遞推方法.電子科學學刊,1997,13(3):424-427.[13]石文孝,韓慶全.基于多輸出差動差分電流傳送器跳耦結構濾波器.通信學報,2000,21(2):30-35.[14]江金光,何怡剛,吳杰.基于電流傳送器的橢圓函數濾波器設計.電路與系統學報,2000,1(5):32-37.[15]何怡剛,江金光,吳杰.通用有源電流模式濾波器.電子學報,1999,27(11):21-23.
