一種適用于毫米波段的新型集成平面回音壁模介質諧振器
A NEW TYPE OF INTEGRATED PLANAR WHISPERING GALLERY MODE DIELECTRIC RESONATOR SUITABLE FOR MILLIMETER WAVE INTEGRATED CIRCUITS
-
摘要: 本文根據(jù)回音壁模的特性,討論了一種適用于毫米波段的新型集成平面回音壁模介質諧振器。采用X.H.jiao(1987)的分析思想,導出了特征方程,并進行了詳細的理論分析和諧振頻率的數(shù)值計算,計算結果與有關文獻相當吻合。結果表明,該諧振器特別適用于毫米波集成電路。Abstract: According to the behaviours of the whispering gallery modes, a new type of integrated planar whispering gallery mode dielectric resonator is discussed. The characteristic equation is derived by applying the method proposed by X. H. Jiao(1987). The calculated values show in good agreement with that in the previous papers. The results obtained show that this type of resonator is very suitable for millimeter wave integrated circuits.
-
Arnaud. J, Vedrenne C. IEE Proc.-H, 1982, 129(4): 183-187.[2]Cros D, Guillon P. IEEE Trans on MTT, 1990, MTT-38(11): 1667-1674.[3]Guillon P.[J]. Microwave RF.1987,9:75-[4]Jiao X H, Guillon P, Bermudes L. Infrared and Millimeter waves, 1989, 10(8): 519-528.[5]Jiao X H, Guillon P, Cros D. IEEE Trans on MTT, 1989, IVITT-37(2): 432-437.[6]Cros D. Electron. Lett., 1988, 24(13): 797-798.[7]Jiao X H. IEEE Trans. on MTT, 1987, MTT-35(12): 1169-1175.[8]Rayleigh L. Phil. Mag., 1910, 20(12): 1001-1004.[9]Wait J R. Radio Sci, 1967, 2(9): 1005-1017.[10]昊萬春.微波豪米波與光集成電路的理論基礎.西安:西北電訊工程學院出版社.1985: 68-70. -
