掃描電子束在絕緣襯底上生長單晶硅薄膜(SOI)的實驗研究
THE GROWTH OF MONOCRYSTALLINE SILICON THIN FILM ON INSULATOR (SOI) BY SCANNING ELECTRON BEAM
-
摘要: 在絕緣襯底上生長單晶硅薄膜,即SOI技術,是近年發展起來研制三維集成電路的一項新技術。本文討論了利用掃描電子束對淀積在SiO2上的多晶硅薄膜進行改性的實驗。采用籽晶液相外延形成單晶硅薄膜。本實驗的重點在于摸索電子束的功率密度、掃描速度、襯底的溫度和樣品結構等因素對形成單晶硅薄膜質量的影響。實驗取得了較好的結果,獲得了20025m2的單晶區。
-
關鍵詞:
- 單晶硅薄膜; SOI技術; 材料改性
Abstract: An experiment for preparation of SOI films by using scanning electron beam to modify polycrystalline silicon on SiO2 is presented. This method takes on the lateral epitaxial growth of liquid phase crystallon to form monocrystal Si films. The effects of beam power density, scanning velocity, temperature of substrates and the construction of samples on the quality of the monocrystalline silicon films were discussed. A good experimental result has been obtained, the mono-crystalline silicon zone is nearly 20025m2. -
Gat A, et al. Appl. Phys. Lett., 1978，33(8): 775-778.[2]Ohmura Y, et al. IEEE Electron Devices Lett., 1983, EDL-4(3):57-59.[3]Emery K, et al. SPIE-Society of Photo-Optical Instrumentation Engineers, Vol-459, Laser Assisted Deposition, Etching and Doping, 1984:82-89.[4]Hopper G F, et al. Electron. Lett., 1984, 20(12): 500-501.[5]Kawamura S, et al. Laser-Induced Lateral Epitaxial Growth of Si over SiO2, Extended Abstracts of the Electrochem. Soc., Spring Meeting, Montreal, Canada; 1982,243-244.[6]Bradbury D R, et al. J.Appl. Phys., 1984, 55(2):519-523.[7]張旭光,李映雪,王陽元,朱忠伶.電子學報,1989,17(5): 1-7.[8]Shahidi, et al. Fabrication of CMOS on Ultrathin SOl obtained by Epitaxial Lateral Overgrowth and Chemical-Mechanical Polishing. IEDM-International Electron Devices Meeting-Technical Digest 1990, San Francisco, CA: Dec. 9-12, 1990, Sponsored by Electron Devices Society of IEEE: 25.2.1-25.2.4. -
