基于旁瓣電平和主瓣偏移的光控線性相控陣列子陣數確定方法
Determining of Subarray Number Based on Sidelobe Level and Mainlobe Deviation for Optically Linear Phased Array
-
摘要: 在光控相控陣列系統物理模型的基礎上,分析了子陣數與旁瓣電平和主瓣偏移的關系,給出了基于旁瓣電平和主瓣偏移相結合的、直接數值搜索子陣數的算法及其實現過程,并通過計算機仿真驗證了該方法的正確性.
-
關鍵詞:
- 相控陣列; 瞬時帶寬; 子陣劃分; 數值搜索
Abstract: This paper, based on the physical model of optically phased array, analyzes the relationship between the number of subarray and the sidelobe level and mainlobe deviation. It gives the realization process of the algorithm based on the combining the sidelobe level and the mainlobe deviation for solving the number of subarray by directly numerical search. And this method is verified to be correct by computer simulation. -
Mailloux R J. Phased Array Antenna Handbook. Boston-London,Artech House, 1994.[2]張光義著.相控陣?yán)走_(dá)系統.北京,國防工業出版社,2001:323-333.[3]Mailloux R J. Array grating lobes due to periodic phase,amplitude, and time delay quantization[J].IEEE Trans. on Antennas and Propagation.1984, 32 (12):1364-[4]張直中.論寬帶相控陣?yán)走_(dá)的戰術優越性.電子學報,1993,31(3):86-92. -
