大功率電子器件蒸發冷卻電極溫度場的計算
A CALCULATION ON THE TEMPERATURE FIELD OF THE VAPORIZATION COOLING ELECTRODE USED IN HIGH POWER ELECTRON DEVICE
-
摘要: 陽極或收集極的散熱問題是大功率電子器件的基本問題之一。近廿年來雖發展了高效率的蒸發冷卻散熱結構;但其設計仍停留在模擬和經驗設計階段。本文給出了蒸發冷卻電極的數學模型及其求解方法;討論了這種數學物理方程的非線性和多值解性質;并以典型的大功率電子管蒸發冷卻陽極為例,用數字計算機求解出內部溫度場的分布;為蒸發冷卻電極的設計提供了分析根據。據此可進行結構設計,估價給定結構的散熱能力。
-
關鍵詞:
Abstract: The heat dissipation of anodes or collectors is one of the essential problems in the design of high power electron device. In recent twenty years high efficient vaporization cooling structure has been developed, but its design is still done by means of simulation or empirically. In this paper, a mathematical model for the vaporization cooling eleetrode and its solving method are provided. The nonlinear and multi-valued proporties of this mathematical physical equation are discussed. As an example, a numerical solution of inner temperature field in a typical vaporization cooling electrode, an anode of high power electron tube has been given with digital computer. On the basis of these results, the design of vaporization cooling electrode and estimation of its heat dissipation capability are possible. -
李子才,一類非線性熱傳導方程的守恒型格式與逐次超松弛牛頓法最優松弛因子的選取(尚未發表). -
