適用于毫米波集成電路的陷波空心鏡象波導
TRAPPED HOLLOW IMAGE GUIDE FOR MILLIMETERWAVE INTEGRATED CIRCUITS
-
摘要: 本文分析了一種新的適用于毫米波集成電路的介質波導結構陷波空心鏡象波導,用等效介電常數和橫向表面阻抗法從理論上分析了該結構的色散特性,并討論了各尺寸對色散特性的影響,給出了若干數值例子。
-
關鍵詞:
Abstract: A noval dielectrie waveguide structure suitable for millimeter-wave integrated circuits, called trapped hollow image guide, is described. A method of analyzing wave propagation in this structure is developed by using effective dielectric constant approach and surface impedances. The numerical results and discussion are given. -
T. Itoh, IEEE Trans. on MTT, MTT-24(1976), 821.[2]W. McLevige, T. Itch and R. Mittra, IEEE Trans. on MTT, MTT-23(1975), 788.[3]R. M. Knox and P. P. Toulios, A V-band Receiver Using Image Line Integrated Circuits, in Proceeding of the National Electronics Conference, Vol. 29, pp. 489-492, Oct. 1974.[5]P. P. Toulios, Image Line Millimeter Wave Integrated Circuits Directional Coupler Design, Proc. of the National Electronics Conference, Chicago, IL, Dec: 1970.[6]R. M. Knox, IEEE Trans. on MTT, MTT-24(1976), 806.[7]T. Itoh and J. Rivera, A Comparative Study of Millimeter Wave Transmission Lines, 6th Inter.Conference on Infrared and Millimeter Waves, Digest, W-4-1, Miami Beach, FLA, Dec. 1981. -
