非線性直流故障電路的規范型分段線性分析
CANONICAL PIECE WISE-LINEAR ANALYSIS FOR NONLINEAR DC FAULT CIRCUITS
-
摘要: 本文應用規范型分段線性法進行了非線性直流故障電路的分析,求解了預先選為測試端口的端口電壓值。該法需要的貯存量少,經有限步即可得到解答,計算效率高,并且適用于含有多端口非線性元件的電路,是一個故障診斷測試前模擬法,是分析測試前故障電路的好方法。
-
關鍵詞:
- 模擬電路; 模擬電路故障診斷; 非線性直流故障電路; 規范型分段線性分析
Abstract: The canonical piecewise-linear method is used to analyse the nonlinear DC fault circuits and determine the potential at the preseleted test ports in the circuit. The method needs less storage capacity and has higher computing efficiency. It is a good method for analysis of fault circuits. -
L.O. Chua, A.C.Deng, Canonical Piecewise-Linear Modeling, U. C. Berkeley ERL Memo. UCB/ERL M85/35, April 26, 1985.[2]P. M, Lin, Y.S. Elcherif, Int. J. Circuit Theory Appl., 13(1985), 149-172.[3]J. O. Chua, Robin L.P. Ying, IEEE Trans. on CAS, CAS-30(1983), 125-140.[4]L.O. Chua, P. M. Lin,Computer-Aided Analysis of Electronic Circuits, Algorithms and Computations To, chniques, Pretice-Hall Englewood Cliff, N. J., 1975. -
