星載TWT放大器EPC的諧波分析
Analysis on Harmonic of EPC Used in Spaceborne TWTA
-
摘要: 星載TWT放大器EPC由于其獨特的電路結構使其諧波具有復雜的頻譜分布并對其工作的可靠性有很大的影響。該文應用調制理論分析了EPC調制諧波的成因，給出了其頻譜分布的計算結果并與實際測量數據進行了對比，其結論對降低EPC諧波造成的EMI，進而為提高TWTA的可靠性提供了依據。
-
關鍵詞:
- 諧波;調制;EPC;可靠性
Abstract: Due to the circuit topology of EPC used in spaceborne TWT amplifier, its harmonic has complex spectrum and great effect on reliability. In this paper, the modulation theory is applied to analyze the cause and calculate the spectrum of harmonic of EPC, also the experimental results are given. The conclusion of this paper will help both in suppressing the harmonic of EPC and improving the reliability of TWTA. -
Larsen E V, Baker D H, Mclver J C. Low order harmonic interaction on a.c./d.c, schemes. IEEE Trans. on Power Delivery, 1989, 4(1): 438-450.[2]程煜烽,王兆申.星載行波管放大器雜波譜抑制的研究.電子與信息學報,2002,24(1):103-107.[3]Sakui M, Fujita H, Shioya M. A method for calculating harmonic current of a three phase bridge uncontrolled rectifier with d.c. filter. IEEE Trans. on Indus. Electron., 1989, 36(3): 434-440.[4]Lihua Hu, Robert Yacamini. Harmonic transfer through converters and HVDC links[J].IEEE Trans. on Power Electronics.1992, 7(3):514-525[5]Rasgid M H, Maswood A I. Analysis of three phase a.c./d.c. converter under unblance supply conditions. IEEE Trans. on Industrial Applications, 1988, IA-24(3): 449-455. -
