任意多層介質波導本征值問題的網絡分析
NETWORK ANALYSIS OF EIGENVALUE PROBLEMS FOR MULTILAYER DIELECTRIC WAVEGUIDE CONSISTING OF ARBITRARY NUMBER OF LAYERS
-
摘要: 本文用微波網絡的方法求解了任意多層介質波導的本征值問題;編制了一個分析N層介質波導色散特性和電磁場分布,并具有計算機圖形功能的通用程序。通過對非對稱多層介質波導場分布的實例分析,形象地說明了介質分支波導中模式轉換和分裂的過程,并討論了模式轉換的一般規則。
-
關鍵詞:
- 介質波導; 微波網絡分析法; CAA
Abstract: In this paper, the eigenvalue problems of multilayer dielectric waveguide consisting of arbitrary number of layers are solved by microwave network method. A general program with the function of computer graphics has been made for analyzing the dispersion characteristics and the electromagnetic field distribution of N layer dielectic waveguide. As an example of practical applications, the procedure of mode conversion and separation in delectric branching waveguide is vividly demostrated through analyzing the field distribution of asymmetric dielectic structure and the general rules of mode conversion are discussed. -
S. T. Peng and A. A. Oliner, IEEE Trans. on MTT, MTT-29(1981), 843.[2]S. T. Peng, S. J. Xu and F. K. Schwering, Scattering of Surface Wave by Non-uniform Dielectric Wave-guides, IEEE International Microwave Symposium, St, Louis, MO, U. S. A. June 1985, pp 627.[3]S. T. Xu, S. T. Peng and F. K. Schwering, Effest of Transition Waveguides on Dielectric Waveguide Directional Coupler, IEEE International Microwave Symposium, Baltimore, MO. U. S. A. June 1986. -
