基于多分辨分析計算波導的TE和TM模
COMPUTATION OF TE AND TM MODES IN WAVEGUIDES OF ARBITRARY CROSS SECTIONS BASED ON MULTIRESOLUTION ANALYSIS
-
摘要: 本文根據多分辨分析理論，給出了計算具有任意橫截面波導的TE模和TM模的一種方法。在該方法中，用尺度函數把場分量(Ez或Hz)近似為級數，通過變分公式把波導問題化為矩陣方程。并且把波導截面分為許多矩形區域，用三階B-樣條函數，推出了矩陣元素的具體表達式。為了驗證該方法，以三種不同的波導為實例進行了計算。
-
關鍵詞:
- 多分辨率分析;尺度函數;B-樣條;波導
Abstract: Based on multiresolution analysis,a method for computation of TE and TM modes in arbitrary cross sections is described.The method uses expansion in terms of scaling functions to approximate the axial field component (Ez or Hz) and transforms the field equation into a matrix equation by applying a variational formulation.The matrix elements are formulated by dividing the waveguide cross section into rectangles and using third-order B-spline.Numerical examples are provided for various waveguides to show the validity and effectiveness of the method. -
Montgomery J P.On the complete eigenvalue solution of ridged waveguide.IEEE Trans.on MTT,1971,MTT-19(6):547-555.[2]曹世昌．電磁場的數值計算與微波的計算機輔助設計．北京：電子工業出版社，1989,第三章．[3]Israel M,Miniowitz R.An efficient finite element method for nonconvex waveguide based on Hermitian polynomials.IEEE Trans.on MTT,1987,MTT-35(11):1019-1026.[4]Sun W,Balanis C A.MFIE analysis and design of ridged waveguides.IEEE Trans.on MTT,1993,MTT-41(11):1965-1971.[5]Krumpholz M,Katehi L P B.MRTD:new time-domain schemes based on multiresolution analysis.IEEE Trans.on MTT,1996,MTT-44(6):555-571.[6]Steinberg B Z,Leviatan Y.On the use of wavelet expansions in the method of moments.IEEE Trans.on AP,1993,AP-41(5):610-619.[7]Steinberg B Z,Leviatan Y.A multiresolution study of two-dimensional scattering by metallic cylinders.IEEE Trans.on AP,1996,AP-44(4):572-579.[8]Mallat S G.A theory for multiresolution signal decomposition:The wavelet representation.IEEE Trans.on PAMI,1989,PAMI-11(7):674-693.[9]崔錦泰著,程正興譯.小波分析導論.西安:西安交通大學出版社,1995,17-24. -
