10%帶寬兆瓦級速調管放大器
A TEN PERCENT BANDWIDTH HIGH-POWER PULSED KLYSTRON AMPLIFIER
-
摘要: 正 長期以來,人們對雷達發射機用的兆瓦級末級發射管的效率-帶寬特性和增益-帶寬特性一直很感興趣。而且雷達對發射管相位-頻率線性,增益平坦性和功率幅值平坦性的要求也越來越高。但是目前微波管產品中,尚沒有在這樣的功率電平下帶寬寬于10％的管子。由于速調管在大功率、高增益、高效率等方面與其他微波管相比,仍占有較大的優勢,因此,近十幾年來,國際上許多微波管公司,廠家在展寬速調管帶寬方面仍進行著不少具有實際意義的研究工作
-
關鍵詞:
Abstract: This paper describes a pulsed klystron amptifier tube with 1-2 MW peak out-put power is described. It operates at the low end of S-band. The 1 dB bandwidth is greater than 10% f0 with 40 dB gain. The tube has an overlapping mode extended interaction output section and a six cavity buncher section. It is very stable in operation. It has nearly constant gain accross the entire band. -
