基于并矢格林函數分析環繞微帶共形天線
ANALYSIS OF MICROSTRIP WRAP-AROUND ANTENNA BASED ON DYADIC GREEN S FUNCTIONS
-
摘要: 本文導出了涂覆無耗介質層的無限長金屬圓柱結構的并矢格林函數以及與這種結構共形的微帶天線輻射場的一般表達式,并利用表面電流模型法研究了介電常數、介質層厚度和金屬圓柱體半徑對環繞微帶共形天線方向圖的影響。
-
關鍵詞:
- 環繞微帶共形天線; 并矢格林函數; 天線方向圖
Abstract: The general field expressions for conformal microstrip antennas on cylindrical body are derived based on dyadic Green s functions for concentric-cylindrical layered media. The radiation patterns for various radii, permittivities, and thickness of the dielectric layer of a microstrip wrap-around antenna are obtained using the general field expressions and electric surface current model. -
Munson R E. IEEE Trans. on AP, 1974, AP-22(1):74-78.[2]Ashkenazy J, Shtrikman S, Treves D. IEEE Trans. on AP, 1985, AP-33(3):295-300.[3]Habashy T M, et al. IEEE Trans. on AP, 1990, AP-38(5): 722-731.[4]Yang C, Ruan Y Z. Electron. Lett., 1993, 29(6):512-514.[5]Tai C T. Dyadic Greens function in electromagnetic theory. Scranton: Intezt Educational Publiahers, 1971,Chapter 7. -
