非互易網絡的無耗約束條件
Lossless constraint conditions of non-reciprocal networks
-
摘要: 該文論述了在非互易條件下，無源無耗網絡的各種約束表征：例如，阻抗[Z]矩陣可以存在實部。它并不與能量定律相悖,即在這種情況下，阻抗矩陣中的電阻并不代表損耗，其負阻也不表示有源增益；傳輸[A]矩陣也反映出|det[A]|=1的似互易特性。文中給出了具體實例。
-
關鍵詞:
- 非互易; 無源; 無耗網絡; 阻抗實部; 似互易特性
Abstract: The lossless constraint conditions of the non-reciprocal passive networks are studied in this paper. It is shown that the impedance matrix [Z] of a non-reciprocal lossless network has the real part, but it is compatible with the law of conservation of energy. In the non-reciprocal case, the positive resistances of the impedance matrix do not represent the. loss of the network, and the negative resistances do not represent the active gain. In addition, the transmission matrix [A] has the characteristic of |det[/l]|=l, which is called as the quasi- reciprocity. The realistic examples are given hi this paper. -
梁昌洪,史小衛,電磁網絡的無耗性與互易性,電子科技雜志,1992,6(1),25-27.[2]梁昌洪,計算微波,西安,西北電訊工程學院出版社,1985,16-18.[3]吳萬春,梁昌洪,微波網絡及其應用,北京,國防工業出版社,1980,25-35.[4]李潤旗,微波網絡理論的新進展及其應用,[博士論文],西安電子科技大學,1991.7.[5]林守遠,廣義模對稱定理的推廣,電子科學學刊,1991,13(6),637-639. -
