天線開關管頻率特性的計算機輔助設計
CAD of Bandpass Characteristics of Microwave Duplexer Tube (TR Tube)
-
摘要: 該文以集總參數元件為理論模型，給出天線開關(TR)管頻率特性的理論表達方程組，用FORTRAN語言對它們進行了模擬計算；給出了參差調諧、非四分之一波導波長耦合線以及元件損耗等一些非標準因素對頻帶特性的影響，給出了四元件TR管的參差調諧及耦合線長度的最佳值，并與試驗結果進行了比較；在程序設計中采用了計算機自動選擇最佳參數以及屏幕圖形方式技術直接顯示計算曲線的方法。該文所采用的理論模型及計算方法也適用于一般微波濾波器的分析模擬。
-
關鍵詞:
- 天線開關管（TR管）; 微波放電器件; 微波濾波器
Abstract: The simulation calculation with the computer using FORTRAN language for frequency characteristics of the microwave duplexer tube (TR tube) is described in this pa-per. It is based on the theory of microwave four terminal networks with lumped parameter elements. The theoretical equations expressing the frequency charcteristics of TR. tube is given firstly. Then the effects of some factors, such as the staggered tuning, the length of coupling transmission line, and the element loss on the frequency characteristics are calcu-lated and discussed. The optimum values of staggered timing and optimum length of the line of a iour-resonate-elemeiit TR tube are given, and compared with the experimental data. In the program, the optimum parameters of the TR tube can be chosen automatically, and the curve of frequency characteristics is directly shown in the screen. The calculating model and method are also suitable for conventional microwave filter. -
電子管手冊編委會主編.天線開關管設計手冊.北京:國防工業出版社,1983,第三章.[2]Kraszewski A.Microwave Gas Discharge Devices.London Ihfie Books Ltd,1967,Chap.4.[3]ЛебедевидрИв. РезонансныеРазрядникиАнтенныхПереключателей. Москва: СоветскоеРадио, 1976, лава3.[4]Smullin L D, Montgomery C G. Microwave Duplexers. McGraw-Hill Book company, 1948, Chap.3[5]柯錦松等.寬帶天線開關管頻率特性的理論計算.電子科學學刊,1991,13(1):42-47. -
