均勻磁場聚焦部分屏蔽流電子注的一種設計方法
A METHOD OF THE DESIGN OF ELECTRON BEAMS FROM PARTIALLY SHIELDED CATHODE WITH UNIFORM MAGNETIC FOCUSING FIELD
-
摘要: 本文敘述了適用于軸對稱強流電子光學系統各種磁結構的部分屏蔽流過渡區的設計方法。通過綜合選取磁系統和電子槍參數,實現了磁系統與電子槍的最佳匹配,獲得了屏蔽系數大于0.8,波動小于1％的電子注。
-
關鍵詞:
Abstract: This paper describes a method of the design of the transition region of the electron beams from partially shielded cathode. This method is applicable to magnetic focusing structures of the axisymmetric high-density electron beam. Through synthetical choice of the parameters of a magnetic system and an electron gun, a optimum matching between the magnetic and the electron gun is obtained. So good results are given: a shielding coefficient Kc is higher than 0.8, a ripple ratio of the electron beams is less than 0.01. -
V. Bevc.[J].J. L. Palmer and C. ssskind, the Journal of the British I. R. E..1958,18:-[2]И.В.Алямовский著,黃高年譯,電子注與電子槍,電子管技術編組,1974年.[3]電子管手冊編委會,微波管電子光學系統設計手冊,第五章,國防工業出版社,1981年.[4]電子管手冊編委會,強流電子槍優選系列,國防工業出版社,1979年. -
