計算任意形狀導體表面電流分布的節點單元電流模型
NODE UNIT CURRENT MODEL FOR CALCULATINGSURFACE CURRENT DISTRIBUTION ONARBITRARY SHAPE CONDUCTORS
-
摘要: 本文提出了計算任意形狀導體表面上感應電流分布的一種新的電流模型節點單元電流模型。這種模型擺脫了在建立電流模型時傳統理論模式的局限,顯著地減少了計算電流分布所需未知量的個數。文中還給出了利用這種模型計算一些典型問題的結果,它們和用其它方法(包括嚴格解)得到的結果非常一致。
-
關鍵詞:
- 近場分析; 表面電流分布; 面片模擬; 節點單元電流模型
Abstract: A new type of current model, defined as node nuit current model, for calculating current distribution on arbitrary shape conductors is presented. By using this model, the number of unknowns necessary for MM solution of current distribution is decreased greatly. The current solutions for typical problems are given. They are in agreement with those obtained by exact formulas and other approaches. -
N. N. Wang, J. H. Richmond, M. C. Cilreath, IEEE Trans. on AP, AP-23(1975)3, 376-382.[2]J. J. H. Wang, Radio Sci., 13(1978)6, 947-952.[3]J. Singh, A.T.Adams, IEEE Trans. on AP, AP-27(1979),4, 531-535.[4]A.W.Glisson, D. R, Wilton, IEEE Trans. on AP, AP-28(1980)5,593-603.[5]S. M. Rao, D. R. Wilton, A. W. Glisson, IEEE Trans. on AP, AP-30(1982)3,409-418. -
