Ka波段鎖相系統研究
STUDY OF Ka-BAND PLL SYSTEM
-
摘要: 利用多環方案,研制了八毫米波鎖相源系統。實驗表明,34.7GHz頻率點輸出的相位噪聲指標(傅氏頻率為1kHz時)為-78dBc/Hz,雜散優于-60dBc,輸出功率大于40mW。Abstract: An 8mm wave PLL system is designed and manufactured by use of multi-loops. It is measured that the phase noise of mm-wave PLL source is-78dBc/ Hz (Fourier frequency is 1kHz offset carrier 37.4 GHz), spurious is lower than-60 dBc, output power is higher than 40mW.
-
H.K. Microwave Inc. Microwave J. 1991, 34(4):139-140.[2]張有正,等.頻率合成技術.北京:人民郵電出版社,1984,71-79.[3]杜正彌,等.中山大學學報,1982,21(1): 54-62.[4]鮑景富,等.全國微波年會論文集(下).合肥:1993,756-759.[5]Vadim M. Frequency Synthesizers Theory and Design.[J].Third Edition, New York;John wiley Sons.1988,:-[6]連漢雄編著.微波鎖相振蕩源.北京:人民郵電出版社,1982,210-220.[7]陳捷平,等.微波學報,1992,31(4): 44-48.[8]Davis R G. IEEE Trans. on MTT, 1991，MTT-39(10):1746-1753. -
