迴旋行波管中波型耦合系數的計算
CALCULATION OF THE COUPLING COEFFICIENTS BETWEEN THE EIGENMODES IN GYRO-TRAVELING WAVE AMPLIFIER
-
摘要: 本文用磁流體力學方程組推導了縱向磁化迴旋漂移相對論電子束的介電張量,然后將迴旋行波管作為部分填充各向異性介質的波導,計算了各本征模之間的耦合系數。計算結果表明,只有角向變化次數相同的模才發生耦合。本文對工作在非基模的迴旋脈塞器件估計模式純度有一定實用價值。
-
關鍵詞:
Abstract: The dielectric tensor of the longitudinally magnetized relativistically gyrating and drifting electron beam is derived by means of the MHD equations. The coupling coefficients between various eigenmodes are then calculated by regarding the Gyro-TWA as a waveguide partially filled with an anisotropic medium. Analysis shows that only those modes with the same azimuthal index couple with each other. The results in this paper are of use for gyrotron devices operating in non-basic mode in estimating mode pureness. -
黃宏嘉,微波原理,科學出版社,1963.[3]王俊毅、李敦復,中國科學(A輯),1982年,第9期,第824頁,附錄. -
