輕便型釤鐠鈷永磁迴路
A LIGHT WEIGHT MAGNETIC CIRCUIT WITH SmPrCo MAGNET
-
摘要: 正 (一)引言 本文介紹3cm波段速調管上使用的均勻場聚焦釤鐠鈷(Sm Pr Co)永磁迴路。它的磁間隙長度Lg=67.3mm,間隙處均勻區最強場強Bmax=2700 Gs,均勻區的場強波動為4％。SmPrCo磁鋼重5kg,磁系統總重量為8.6kg,用于峰值功率為50kw的速調管,獲得了滿意的結果。電子束通過率達9899％。(二)磁迴路的設計和結果 聚焦磁場決定于電子槍的光學系統、高頻互作用區和進入
-
關鍵詞:
Abstract: A SmPrCo PM focusing system for 3 cm klystron is reported. The magnetic gap of the magnetic system is 67.3 mm. The maximum field intensity in the gap is 2700Gs. The fluc-tuation of the field intensity is 4%, the weight of the SmPrCo magnet is only 5 kg. The total weight of the magnetic system is 8.6 kg. The magnetic system has been used for a 50 kW klystron, and the results obtained are satisfactory. The beam transmission of the klystron is above 98%. -
電子管設計手冊編輯委員會,大功率速調管設計手冊,國防工業出版社,1979年.[2]中國科學院電子學研究所八室,強流電子光學計算方法講義,1974年.[3]微波電子管設計手冊編寫小組,微波管設計手冊,1975年. -
